PAT-01-0174
ELECTRICAL CHARACTERISTICS:
1、INDUCTANCE： 1.0KHz at 1.0V (AMBIENT TEMPERATURE 25℃)
L1-4：1.5mH Min
2、LEAKAGE INDUCTANCE：1.0KHz at 1.0V Short Other Pin
LK1-4：100uH Max
3、DC RESISTANCE：AMBIENT TEMP 25℃
R1-4：0.55Ω Max
4、HI-POT TEST：
PRI TO SEC AC1.0KV/50Hz/5mA/60S
COIL TO CORE AC1.0KV/50Hz/5mA/60S
5、INSULATION RESISTANCE TEST：
COIL TO COIL AND COIL TO CORE DC500V 100 MΩ Min
